ZL-HGYDJPDT-004
Source:ZhongLi Tools  Time:2023-10-31 04:26:59  Views:184

Product Features

Main Technical Parameters
Diameter (mm) Matrix thickness(mm) Blade size(mm) Number of blades (Pcs) Application
1200 5.5 24*6.6/7.4*12(15)(20) 80 Granite
2200 9.0 24*10.2/11.0*12(15)(20) 132 Granite
2500 9.0 24*10.2/11.0*12(15)(20) 140 Granite
2800 9.3 24*10.5/11.5*12(15)(20) 156 Granite
3000 9.5 24*12.0/13.0*12(15)(20) 160 Granite
3500 9.5 24*12.5/13.5*12(15)(20) 180 Granite
Tips:Other specifications can be customized according to customer needs.
Product Introduction
1. Good cutting effect: fast and smooth cutting, and flat surface of the large plate.
2. The unique design reduces the friction between the blade and the surface of the stone, allowing the diamond to be quickly exposed, with high cutting efficiency, fast cooling speed, and good debris removal effect.
